TL300B

Advanced Fingerprint Lock with Bluetooth

  • Semi-conductive Fingerprint Sensor
  • Mobile Management
  • Reversible Design
  • Low Power Consumption

Semi-conductive Fingerprint Sensor

  • Fast verification speed for dry and rough fingers

Voice Guide

  • Easy to operate; support English, Spanish and Portuguese

Low Power Consumption

  • New hardware design supports about 3 years of battery life

Mobile Management

  • Manage your lock via ZK SmartKey App with your phone

Lockout Mode

  • All normal users (other than admin) will be locked out

Reversible Design

  • Fit for all door opening directions
Material Zinc Alloy
Mortise China Standard Anti-theft Mortise
User Capacity 100
Fingerprint Sensor Semi-conductor (silicon)
Card Reader Mifare Card Supported
Communication BLE4.0
Language English / Spanish / Portuguese
Power Supply 8 * AA Alkaline Battery (not included)
Temperature -20 °C to 55 °C
Door Thickness 38 - 60 mm (standard)
Dimensions (W*L*D) Front: 78 * 340 * 31 (mm)
Back: 78 * 340 * 27 (mm)
Color Options Dull Nickel / Black

TL300B Leaflet V1.2_20200219

0.36 Mb Data Sheet
2020-03-13
Download

TL300 Installation Guide

3.13 Mb Installation Guide
2020-03-13
Download

TL300 User Manual V1.0_20200220

1.25 Mb User Manual
2021-03-13
Download
