Energy Saving Switch

High-Power Energy Saving Switch

Energy cost accounts for a large proportion of the daily cost management of hotels. No matter how the guests behave, the hotel itself should have deployed an energy-saving system in advance. An energy-saving switch is an indispensable part of the available equipment to help hotels save energy. When a user removes the card from the energy-saving switch for more than 10 seconds, the controller will turn off the power in the room, such as the AC power and the lights. With the help of the energy saving switch, hotel operators can easily avoid unnecessary energy costs. For example, When guests leave the room with their room key, the air conditioning will be turned off automatically.

Type IC
Optoelectronic
Material PC
Maximum Current IC: 30A / 80A
Optoelectronic: 30A
Power Supply AC 85V-264V
Maximum Power IC: 6.6kW / 17.6kW (220V)
Optoelectronic: 6.6kW(220V)
Static Current <23mA
Delay Time ≤10s
Card Type IC: RLEC-M1 Card
Optoelectronic: All card types
Working Temperature 25°C to 55°C
Working Humidity <75% RH
Dimensions 87*86*43 (mm)(W*H*D)

Energy Saving Switch_IC_Datasheet_20251027

0.1 Mb Data Sheet
2026-03-19

Energy Saving Switch_Photoelectric_Datasheet_20250804

0.09 Mb Data Sheet
2026-03-19
